Original Deep Sea DSEE400 Engine Only Control Module Generator Controller
Original Deep Sea DSEE400 Engine Only Control Module Generator Controller
السعر العادي
$568.00 USD
السعر العادي
$1,700.00 USD
سعر البيع
$568.00 USD
سعر الوحدة
/
لكل
يتم احتساب الشحن عند الخروج.
لم نتمكن من تحميل توفر الاستلام
WESPC Original DSEE400 Engine Control Module Deep Sea Electronics E400 Engine‑Only Controller for Generator Systems
Overview
The DSEE400 is an easy to use engine controller designed to provide flexible control with built in monitoring and protection. The DSEE400 is compatible with both electronic and mechanical diesel engines. It is fully configurable for a wide range of applications such as engine driven pumps and compressors.
All of the engine control functions, including the engine start, speed and clutch control can be achieved both automatically & manually. The monitoring and configuration of the system variables allows the DSEE400 to start and stop the engine and increase and decrease engine speed as the output demand requires.
Overview
The DSEE400 is an easy to use engine controller designed to provide flexible control with built in monitoring and protection. The DSEE400 is compatible with both electronic and mechanical diesel engines. It is fully configurable for a wide range of applications such as engine driven pumps and compressors.
All of the engine control functions, including the engine start, speed and clutch control can be achieved both automatically & manually. The monitoring and configuration of the system variables allows the DSEE400 to start and stop the engine and increase and decrease engine speed as the output demand requires.
Specification
- Model: DSEE400, variants: E400-01 (standard), E400-02 (heated LCD)
- Brand: Deep Sea Electronics (DSE), Original
- Product Type: Engine Only Controller
- Front Panel Rating: IP67
- Supply Voltage: DC 8V ~ 35V
- Communication: USB, RS485 Modbus RTU, CAN J1939
- Core Functions: Manual/Auto start, auto speed ramping, clutch control, fill/empty/maintain pump sequence, scheduler, maintenance alarm, 250 event log
- Engine Compatibility: Mechanical diesel engine, CAN J1939 electronic engine
- Dimension: 189 × 125 × 54 mm(7.46 " x 4.94 " x 2.14 ")
- Panel Cutout: 148 × 112 mm(5.83 " x 4.41 ")
- Application: Fire pump, water pump, air compressor, hydraulic power unit
- Warranty: 12 months genuine factory warranty
