DC SUPPLY

CONTINUOUS VOLTAGE RATING
8 V to 35 V Continuous

CRANKING DROPOUTS
Able to survive 0 V for 50 mS, providing supply was at least  10 V before dropout and supply recovers to 8 V. This is achieved without the need for internal batteries. LEDs and backlight will not be maintained during cranking.

MAXIMUM OPERATING CURRENT
200 mA at 12 V
110 mA at 24 V

MAXIMUM STANDBY CURRENT
150 mA at 12 V
90 mA at 24 V

COMMUNICATIONS

USB (Single DSE Controller)
RS232 (Single DSE Controller)
RS485 (Multiple DSE Controllers)
Ethernet (Multiple DSE Controllers)
Ethernet SNMP & SMTP

Net Weight: 1kg
Warranty: 12 months genuine factory warranty
