Genuine HGM6120N SmartGen Automatic Start Controller Generator Set AMF Control Module
Product Overview: HGM6100N series automatic controller, integrating digital, intelligent and network techniques, is used for automatic control and monitoring system of genset. It can carry out functions of automatic start/stop, data measurement, alarm protection and three "remote" (remote control, remote measure and remote communication). The controller uses LCD display, optional display interface including Chinese, English, Spanish, Russian, Portuguese, Turkey, Polish and French with easy and reliable operation.
HGM6100N series automatic controller uses micro-processing technique which can achieve precision measurement, value adjustment, timing and threshold setting etc.. All the parameters can be configured from front panel or use USB interface (or RS485 interface) to adjust via PC. It can be widely used in all types of automatic control system for its compact structure, simple connections and high reliability.
Technical Parameters: Display LCD(132*64) Operation Panel Silicon Rubber Language Chinese & English & Others Digital Input 5 Relay Output 6 Analogue Input 3 AMF ● AC System 1P2W/2P3W/3P3W/3P4W Alternator Frequency 50/60Hz kW/Amp Detecting & Display ● Programmable Interface USB RTC & Event Log ● Scheduled Start Genset ● Maintenance ● DC Supply DC(8～35)V Case Dimensions(mm) 209*166*44 Panel Cutout(mm) 186*141 Operating Temp. (-25～+70)℃
