Original DeepSea DSE2548 LED Output Expansion Module Remote Annunciator 8 Configurable LEDs with Buzzer

Original DeepSea DSE2548 LED Output Expansion Module Remote Annunciator 8 Configurable LEDs with Buzzer

$350.00 USD
$720.00 USD $350.00 USD
Oferta Agotado
Los gastos de envío se calculan en la pantalla de pago.
Genuine Deep Sea DSE2548 DSENet LED Output Expansion Module Remote Alarm Indicator for DSE Genset Controllers

Overview:
The DSE2548 is an output expansion module that can display a maximum of eight individual LED indications.
Each indication is user configurable via the host module. Up to 10 DSE2548 modules can be linked together to provide up to 80 additional LED outputs.
The DSE2548 can be located up to a maximum of 1 km (0.6 mile) away from the host control module.


Specification

  • Model: DSE2548 (2548-01)
  • Brand: Deep Sea Electronics (DSE), Original
  • Type: DSENet LED Output Expansion Module
  • Indicators: 8 configurable LED status lights
  • Extra: Built-in sounder alarm + mute button, link loss warning LED
  • Communication: DSENet®
  • Max distance to host controller: 1000 m
  • Max cascade quantity: 10 pcs DSE2548
  • Supply Voltage: DC 8V ~ 35V
  • Operating Current: 112mA @12V, 53mA @24V
  • Standby Current: 74mA @12V, 35mA @24V
  • Dimension: 180 × 116 × 43 mm
  • Panel Cutout: 154 × 98 mm
  • Max panel thickness: 8 mm
  • Weight: 0.36 kg
  • Compatible Controllers: DSE61xx MKIII, DSE73xx MKII, DSE74xx MKII, DSE86xx MKII series
  • Warranty: 12 months genuine factory warranty

PRODUCT VARIANTS：2548-01 -2548 Output Expansion Module
