High quality oil pressure sensor 622-333 excavator spare parts WESPC . Suitable for FG-Wilson Olympian Genset

High quality oil pressure sensor 622-333 excavator spare parts Replacement for FG-Wilson Olympian Genset

Part Number: 622-333 622333 622-331 622-137
Application:Oil Pressure Sender Switch 622-333 for FG Wilson Olympian Generators
Fit for all FG Wilson and Olympian genset models with 0-10 bar oil pressure gauges (12 and 24V).0-5 bar oil pressure sender/switch also available
Specification:
Terminal G: Is the sender and wire “OP” should be connected to this tterminal - with the wire disconnected
the terminal should read close to 10 ohms to ground with genset off
Terminal WK: Is the switch and *wire “15” should be connected to this terminal - with the wire disconnected
the terminal should read less than 1 ohm to ground with genset off
* Wire “15” will not be connected on 2300 & 2800 electronic engines, since the engine’s Electronic Control
Module will control the low oil pressure shutdown
Shipping Weight: 1.4 pounds
Package Including:Oil Pressure Sender Switch X 1
