M50100THA1600 3-Phase Common Anode Diode Rectifier Module 100A 1600V

M50100THA1600 3-Phase Common Anode Diode Rectifier Module 100A 1600V

$47.00 USD
$0.00 USD $47.00 USD
Sale Sold out
Shipping calculated at checkout.
M50100THA1600 3-Phase Common Anode Diode Rectifier Module 100A 1600V Replace Crydom M50100THA1600


Specification

  • Model: M50100THA1600
  • Type: 3 Phase Common Anode Rectifier Diode Module
  • Rated Continuous Current: 100A
  • Repetitive Peak Reverse Voltage: 1600V
  • Forward Voltage Drop: 1.2V @100A
  • Non-repetitive Surge Current: 1500A
  • Circuit Type: 3-phase common anode
  • Isolation Voltage: 2500V RMS
  • Operating Temp: -40°C ~ +125°C
  • Dimension: 57.5mm × 44.4mm × 24.1mm
  • Connection: 4 screw terminals (AC1, AC2, AC3, DC-)
  • Warranty: 12 months factory warranty
  • Application: Brushless alternator excitation rectifier, diesel genset, generator overhaul, Stamford & Leroy Somer alternator spare parts
