Original DeepSea DSE6110 MKIII Auto Start Generator Controller LCD Display Module
Original DeepSea DSE6110 MKIII Auto Start Generator Controller LCD Display Module
Regular price
$468.00 USD
Regular price
$0.00 USD
Sale price
$468.00 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Genuine Deep Sea DSE6110 MKIII Auto Start Generator Controller Single Genset Manual & Auto Start Control Module
Overview:
The DSE6110 MKIII is an Auto Start Control Module suitable for a wide variety of single, diesel or gas, genset applications.
Monitoring an extensive number of engine parameters, the module will display warnings, shutdown and engine status information on the back-lit LCD screen, illuminated LEDs and remote PC.
The module includes USB connection and dedicated DSENet® terminals for system expansion.
Specification
- Model: DSE6110 MKIII
- Brand: Deep Sea Electronics (DSE)
- Type: Auto Start Generator Controller (Non-AMF)
- Display: Backlit LCD, multi-language, custom startup screen
- Power Supply: 8V – 35V DC, reverse polarity protection
- Measurement: True RMS, 3-phase generator voltage, current, power, energy
- Engine Interface: CAN J1939, MPU magnetic pick-up, alternator frequency
- Communication: USB for configuration, DSENet® expansion port
- I/O: 8 digital inputs, 4 configurable analogue/digital inputs, 6 configurable DC outputs
- Core Function: Manual / auto start, preheat, idle control, built-in PLC, fuel monitoring, maintenance alarm, event log
- Protection: Overspeed, low oil pressure, high temp, over/under voltage, overload, charge fail, E-stop
- Software: DSE Configuration Suite, DSE Assistant
- Mounting: Front panel mounting
- Panel Cut-out: 184mm × 137mm
- Application: Single diesel / gas genset, prime power, auto start engine systems
- Warranty: 12 months genuine factory warranty
216 mm x 158 mm x 43 mm (8.5” x 6.2” x 1.5”)
PANEL CUTOUT SIZE
184 mm x 137 mm (7.2” x 5.3”)
MAXIMUM PANEL THICKNESS
8.0 mm (0.3”)
WEIGHT
0.5kg
PRODUCT VARIANTS
6110-05 - 6110 MKIII Auto Start Control Module
