Original Mebay DC80D Replaced By DC80D MK3 Generator Start Stop Controller AMF Control Unit RS485

Original Mebay DC80D Replaced By DC80D MK3 Generator Start Stop Controller AMF Control Unit RS485

$198.00 USD
$0.00 USD $198.00 USD
Sale Sold out
Shipping calculated at checkout.
Original Genuine Mebay DC80D MK3 4.3 Inch Color Genset Controller CAN J1939 Auto Start Stop Generator Control Panel Local Full Protection No RS485 Modbus No Remote Cloud Monitoring

Wide Application Range

Single-unit fixed industrial diesel generator control cabinet, construction site temporary backup power equipment, small and medium silent standby genset, commercial building emergency power unit, light marine auxiliary power genset, off-grid industrial independent power station, generator maintenance factory, engineering projects focusing on on-site local automatic control and full parameter protection without remote cloud management demand, reliable replacement for traditional small-screen controllers and imported brand control panels.

Product Specifications

  • Brand: Mebay
  • Model: DC80D MK3
  • Core Function: 4.3-inch color screen genset automatic controller, CAN J1939 ECU data reading, full local auto start/stop & fault protection (No RS485 remote cloud, No ATS mains sampling)
  • Working Power Supply: DC8V ~ 36V universal 12V/24V genset battery wide voltage
  • Communication Interfaces: CAN J1939 ECU Bus + USB Local Debug (No RS485 Modbus Remote Port)
  • Display: 4.3-inch 800*480 high-definition TFT color LCD multi-language screen
  • Installation Method: Embedded panel mounting for standard genset cabinet
  • Front Panel Protection Grade: IP54 industrial dustproof & waterproof
  • Operating Temperature: -20℃ ~ +65℃
  • Warranty: 12 months genuine factory warranty
  • Certifications: CE, EMC, RoHS, ISO9001 industrial certification

Common Equipment Failures Solved

  • No screen display after power on: Check DC battery power supply and positive/negative wiring looseness
  • No J1939 engine data reading: Confirm CAN H/CAN L wiring sequence and engine ECU protocol matching
  • USB cannot connect to computer: Check data cable integrity and official software version matching
  • Frequent false alarms during startup: Adjust alarm delay time via local PROG button
  • Need remote APP monitoring/SMS alarm/GPS positioning: Upgrade to DC80DR MK3 + DT4000 remote combination
  • Need mains ATS automatic transfer function: Replace with DC82D/DC82DR ATS dedicated controller
  • Old DC40D MK4 panel upgrade: Direct plug-and-play replacement, no cabinet modification and wiring adjustment needed
